lizpritting

active

Joined: Mon, Feb 20, 2012
0 Posts
No Rating

I'm working with a text that has a width factor of 0.80.  The text appears correctly in the model, but when printed, the opaque background of the text masks the area as if there was a width factor of 1.0, therefore masking more than it needs to, which includes parts of the model.  Is there a way to change the width factor of the masking area as well? This appears to be a revit glitch.

This user is offline

WWHub

site moderator|||

Joined: Tue, May 16, 2006
13079 Posts

The text masking area has always been a little strange.... sorry - I have not ever heard of a way to change this.

This user is offline

HKicsak

active

Joined: Mon, Feb 13, 2012
2 Posts
No Rating

I was curious so I tested some things- could it be your printer? Are you printing to PDF? I would check your settings- raster or vector processing, quality, etc.

I tested with .8 and 1.0 width factors, and both printed- to PDF and directly to my printer.

Granted, I'm using fully updated 2014 and you don't state your version.

This user is offline

lizpritting

active

Joined: Mon, Feb 20, 2012
0 Posts
No Rating

Sorry, I forgot to mention I am using 2015.  I played around some more with print settings - when i print to PDF it works, but when i export DWFs it does not.  Of course, DWF is what i need.  Even changing the width factor back to 1.0 does not seem to help - see attached image (the top text box is width factor 0.8, the bottom is 1.0) - the masking area seems to be somewhere in between.

Any ideas on how to fix the DWF export setting to deal with this issue?

Attached Images

This user is offline

WWHub

site moderator|||

Joined: Tue, May 16, 2006
13079 Posts

I suggest you send the issue to autodesk.... It may be a known issue but if it is not, then maybe they will put it on their to do list......
